Thermalright AXP120-X67: Peak Performance for Low-Profile Builds

Optimize your Small Form Factor (SFF) PC without sacrificing thermal performance. The Thermalright AXP120-X67 is the ultimate low-profile CPU air cooler, combining high-efficiency heat dissipation with an ultra-compact design, ensuring your powerful components run cool and quiet in the tightest chassis.

Key Features & Specifications

• Ultra-Low Profile: With a total height of just 67mm (including the fan), this cooler is engineered to fit most Mini-ITX cases where space is severely limited.
• Powerful Heat Transfer: Utilizes 6 x 6mm high-efficiency heat pipes paired with a premium C1100 Pure Copper nickel-plated base to quickly draw heat away from the CPU IHS.
• Quiet 120mm Slim Fan: The included TL-C12015 PWM fan delivers strong airflow without excessive noise.
  • Air Flow (MAX): 59 CFM
  • Noise Level (MAX): 26.1 dBA
  • Bearing Type: S-FDB Bearing for exceptional durability and smooth operation.

Recommended CPU Usage

The AXP120-X67 provides impressive cooling capacity for its size, making it a highly effective solution for CPUs with moderate to high power consumption when configured appropriately for SFF systems.

• Recommended TDP Range: 65W to 130W
  • Ideal Match: Excellent cooling for mainstream and high-performance CPUs like the AMD Ryzen 5/7 and Intel Core i5/i7 (non-K/non-X series), especially those with 65W base TDPs.
  • Gaming Powerhouses: Highly effective on processors known for low gaming power draw, such as the Ryzen X3D series (e.g., 7800X3D, 5800X3D).
• Core Ultra / High-End CPUs: This cooler is compatible with the latest LGA 1851 socket (used by new Intel Core Ultra series) and can handle powerful K-series/higher-wattage chips, but for best results in SFF cases, we strongly recommend enabling BIOS power limits (e.g., PL1/PL2 set to 125W) to ensure quiet, stable performance under sustained load.

Compatibility: Ready for modern platforms, including Intel LGA 1851, 1700 and AMD AM5 / AM4.

Build the compact, powerful PC you want. Choose the Thermalright AXP120-X67 for superior thermal management where space is scarce.
