Brand: MSI
SKU: MBAM5-X670PROPWIFI

MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX

Interfaces/Ports: HDMI, DisplayPort
Chipset: AMD X670
CPU Socket: AM5
CPU Socket: AM5
# of Memory Slots: 4
Brand: MSI
Memory Technology: DDR5
UPC/EAN: 824142299265
Form Factor: ATX
Ryzen Processor Supported - 128 GB DDR5 SDRAM Maximum RAM - 4 x Memory Slots - IEEE 802.11 a/b/g/n/ac/ax - HDMI - DisplayPort - 6 x SATA Interfaces
Product Details
PRO X670-P WIFI is designed with tons of flexible tools and convenient Wi-Fi solution with DDR5 memory version. Enhanced Power Design: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost

General Information
Manufacturer:
MSI

Manufacturer Part Number:
X670PROPWIFI

Manufacturer Website Address:
http://www.msi.com

Brand Name:
MSI

Product Series:
PRO

Product Model:
PRO X670-P WIFI

Product Name:
PRO X670-P WIFI Desktop Motherboard

Marketing Information:
PRO X670-P WIFI is designed with tons of flexible tools and convenient Wi-Fi solution with DDR5 memory version. Enhanced Power Design: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost

Product Type:
Desktop Motherboard

Processor & Chipset
Chipset Manufacturer:
AMD

Chipset Model:
X670

Total Processor Supported:
1

Processor Socket:
Socket AM5

Processor Supported:
Ryzen

Memory
Number of Memory Slots:
4

Maximum Memory Supported:
128 GB

Memory Technology:
DDR5 SDRAM

I/O Controller
Controller Type:
Serial ATA/600

RAID Supported:
Yes

RAID Levels:
0
1
10
Video
Onboard Video:
CPU Dependent Video

Audio
Audio Channels:
7.1

Network & Communication
Bluetooth:
Yes

2.5Gigabit Ethernet:
Yes

Wireless LAN:
Yes

Wireless LAN Standard:
IEEE 802.11 a/b/g/n/ac/ax

I/O Expansions
Number of Total Expansion Slots:
4

Total Number of PCI Express Slots:
4

Number of PCI Express x1 Slots:
1

Number of PCI Express x16 Slots:
4

Interfaces/Ports
Total Number of USB Ports:
8

Number of USB 3.2 Ports:
2

Number of USB 3.2 Gen 1 Ports:
4

Number of USB 3.2 Gen 2 Type-A Ports:
2

S/PDIF:
Yes

HDMI:
Yes

DisplayPort:
Yes

Number of Network (RJ-45) Ports:
1

Onboard Interfaces
Number of SATA Interfaces:
6

Number of M.2 Interfaces:
4

Total Number of Onboard USB Ports:
9

Number of Onboard USB 2.0 Ports:
4

Number of Onboard USB 3.2 Ports:
5

Physical Characteristics
Form Factor:
ATX

Width:
12"

Depth:
9.6"

Miscellaneous
Brand Compatibility:
AMD

Country of Origin:
China

Warranty
Limited Warranty:
3 Year
Weight: 5 lbs
X670PROPWIFI
MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
X670PROPWIFI
MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
X670PROPWIFI
MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
X670PROPWIFI
MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
X670PROPWIFI
MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
X670PROPWIFI
MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
X670PROPWIFI
MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
X670PROPWIFI
MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
X670PROPWIFI
MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
X670PROPWIFI
MSI PRO X670-P WIFI Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
(Click to see larger image and other views)
List Price: $299.99
Price: $194.99
You Save: $105.00 (35%)
