Brand: MSI
SKU: MB17B660-PROB660MPD4

MSI Motherboard PRO B660M-P DDR4 B660 Socket1700 Max128GB DDR4 mATX Black/Matt

Interfaces/Ports: HDMI, DisplayPort, & VGA
Chipset: Intel B660
CPU Socket: LGA 1700
# of Memory Slots: 4
Brand: MSI
Memory Technology: DDR4 Support
UPC/EAN: 824142286692
Form Factor: MATX
CPU (MAX SUPPORT) i9 - SOCKET 1700 - CHIPSET Intel B660 Chipset - DDR4 MEMORY - MEMORY CHANNEL Dual - DIMM SLOTS 4 - MAX MEMORY (GB) 128
Product Details
Marketing Information
PRO SERIES
PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.

FROZR AI COOLING
Detecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI ENGINE.

FULLY CONTROLLABLE IN BIOS AND SOFTWARE
MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.

EZ DEBUG LED
Ran into trouble? Onboard LEDs for key components will indicate the source of the problem so you know exactly where to look to get it up and running again.

ULTIMATE MOTHERBOARD PROTECTION
Double ESD protection doubles up the grounding layer around the mounting holes, preventing static discharge surges from damaging the motherboard.

FORTIFY YOUR SYSTEM WITH PCI-E STEEL ARMOR
MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points and support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor shields the point of contact from electromagnetic interference.

OPTIMIZE NETWORK FOR LOWER LATENCY!
MSI LAN Manager automatically classifies and prioritizes the latency-sensitive applications, giving you the best online experience with low latency.

Detail Specifications
CPU (MAX SUPPORT)
i9
SOCKET
1700
CHIPSET
Intel B660 Chipset
DDR4 MEMORY
4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHz
MEMORY CHANNEL
Dual
DIMM SLOTS
4
MAX MEMORY (GB)
128
PCI-E X16
1
PCI-E X1
2
SATAIII
4
M.2 SLOT
1
RAID
0/1/5/10
TPM (HEADER)
1
LAN
1x Realtek RTL8111H 1Gbps LAN controller
USB 3.2 PORTS (FRONT)
2(Gen 1, Type A), 1(Gen 1, Type C)
USB 3.2 PORTS (REAR)
1(Gen 2, Type C), 1(Gen 1, Type A)
USB 2.0 PORTS (FRONT)
2
USB 2.0 PORTS (REAR)
4
SERIAL PORTS(FRONT)
1
AUDIO PORTS (REAR)
Realtek ALC897 Codec
DISPLAYPORT
1
VGA
1
HDMI
1
DIRECTX
12
OPERATING SYSTEM
Support for Windows 11 64-bit, Windows 10 64-bit
FORM FACTOR
MATX
Item Dimension (L inchxW inchxH inch)
11 x 11 x 4


PROB660MPD4
MSI Motherboard PRO B660M-P DDR4 B660 Socket1700 Max128GB DDR4 mATX Black/Matt
PROB660MPD4
MSI Motherboard PRO B660M-P DDR4 B660 Socket1700 Max128GB DDR4 mATX Black/Matt
PROB660MPD4
MSI Motherboard PRO B660M-P DDR4 B660 Socket1700 Max128GB DDR4 mATX Black/Matt
PROB660MPD4
MSI Motherboard PRO B660M-P DDR4 B660 Socket1700 Max128GB DDR4 mATX Black/Matt
PROB660MPD4
MSI Motherboard PRO B660M-P DDR4 B660 Socket1700 Max128GB DDR4 mATX Black/Matt
PROB660MPD4
MSI Motherboard PRO B660M-P DDR4 B660 Socket1700 Max128GB DDR4 mATX Black/Matt
PROB660MPD4
MSI Motherboard PRO B660M-P DDR4 B660 Socket1700 Max128GB DDR4 mATX Black/Matt
PROB660MPD4
MSI Motherboard PRO B660M-P DDR4 B660 Socket1700 Max128GB DDR4 mATX Black/Matt
(Click to see larger image and other views)
List Price: $149.99
Price: $124.99
You Save: $25.00 (17%)
