Intel Core i7 (13th Gen) i7-13700F 16 core 24 Thread 5.20GHz Turbo Processor (No Onboard Video)

Product Collection 13th Generation Intel® Core i7 Processors

Code Name Products formerly Raptor Lake

Vertical Segment Desktop

Processor Number i7-13700F

Lithography Intel 7

CPU Specifications

Total Cores 16

# of Performance-cores 8

# of Efficient-cores 8

Total Threads 24

Max Turbo Frequency 5.20 GHz

Intel® Turbo Boost Max Technology 3.0 Frequency - 5.20 GHz

Performance-core Max Turbo Frequency 5.10 GHz

Efficient-core Max Turbo Frequency 4.10 GHz

Performance-core Base Frequency2.10 GHz

Efficient-core Base Frequency1.50 GHz

Cache 30 MB Intel® Smart Cache

Total L2 Cache24 MB

Processor Base Power 65 W

Maximum Turbo Power 219 W

Supplemental Information

Memory Specifications

Max Memory Size (dependent on memory type) 128 GB

Memory Types Up to DDR5 5600 MT/s

Up to DDR4 3200 MT/s

Max # of Memory Channels 2

Max Memory Bandwidth 89.6 GB/s

ECC Memory Supported  - Yes

PCI Express Revision 5.0 and 4.0

PCI Express Configurations - Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes 20

Package Specifications

Sockets Supported FCLGA1700

Max CPU Configuration1

Thermal Solution Specification PCG 2020C

TJUNCTION 100°C

Package Size45.0 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator 3.0

Intel® Thread Director Yes

Intel® Deep Learning Boost (Intel® DL Boost) Yes

Intel® Speed Shift Technology Yes

Intel® Turbo Boost Max Technology 3.0 - Yes

Intel® Turbo Boost Technology - 2.0

Intel® Hyper-Threading Technology - Yes

Intel® 64- Yes

Instruction Set 64-bit

Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States Yes

Enhanced Intel SpeedStep® Technology Yes

Thermal Monitoring Technologies Yes

Intel® Volume Management Device (VMD) Yes

Security & Reliability

Intel® Standard Manageability (ISM) -Yes

Intel® Control-Flow Enforcement Technology Yes

Intel® AES New Instructions Yes

Secure Key Yes

Intel® OS Guard Yes

Intel® Trusted Execution Technology- Yes

Execute Disable Bit- Yes

Intel® Boot Guard Yes

Mode-based Execute Control (MBEC) Yes

Intel® Virtualization Technology (VT-x) - Yes

Intel® Virtualization Technology for Directed I/O (VT-d)- Yes

Intel® VT-x with Extended Page Tables (EPT)- Yes
