The new Lifetime Series Pro 750W ATX12V & EPS12V Power Supply is the latest addition to our line-up of professional power supplies. It provides the ultimate amount of power and performance. Its sleek new design incorporates ascetics with functionality. This design comes with a 135mm cooling fan which reduces heat by 20% and noise by 15 dB. In addition to the reduction of heat and noise, It also comes with sleeved finished power cables which provide better air flow and help reduce cable clutter. Over all this new power supply is the ultimate upgrade or addition to any system. Product Type: Â ATX12V & EPS12V Power Supply Technical Information
Number of Fans: Â 1 Protection Type: Â Short Circuit Inrush Current Thermal Overload Over Temperature Over Voltage Over Current Under Voltage
Reliability
MTBF: Â 100000 Hour Power Description
Input Voltage: Â 230 V AC Input Voltage Range: Â 115 V AC to 230 V AC Output Voltage: Â 3.3 V DC 5 V DC 12 V DC -12 V DC 5 V DC
Input Current: Â 12 A @110 V AC/8 A @220 V AC Frequency: Â 50 Hz 60 Hz
Output Power: Â 750 W Interfaces/Ports
Plug/Connector: Â 1 x Receptacles: Â 1 x 24-pin ATX Motherboard 1 x 4-pin ATX12V Motherboard 1 x 8-pin EPS12V Motherboard 2 x 6-pin PCI-E 1 x 8-pin PCI-E 4 x 5-pin Serial ATA 1 x 4-pin SP4 Floppy Drive 5 x 4-pin LP4 Peripheral Device
Physical Characteristics
Dimensions: Â 3.25" Height x 5.75" Width x 6" Depth Weight (Approximate): Â 6 lb Miscellaneous
Certifications & Standards: Â CE, CB, UL 1950, IEC 60950, FCC Class B Warranty
Standard Warranty: Â Lifetime
|
